Speedrite output transformer (1000, 2000, 3000)

Details

This is the step-up transformer for the smaller Speedrite energizers. It takes the switched pulse from the main module and puts it onto the fence at working voltage, and when it fails the unit typically lights up and appears healthy while the fence reads nothing. On these units the usual killers are a nearby strike, a surge that got past the internal lightning rod, or moisture. Energizers in unheated shops go through a condensation cycle every time the temperature swings, and over years that finds its way into windings. This transformer is listed for the 1000, 2000 and 3000 series. Those models span more than one production run and Speedrite does not publish a per-serial fitment table for internal parts, so confirm against your unit's model and serial plate before ordering. Fit it with the unit unplugged and the capacitors discharged, and if the unit is also showing damage on the main module, replace both. A transformer put into a faulty drive circuit will not last.

Specifications

Brand

Speedrite

Product name

Speedrite output transformer (1000, 2000, 3000)

Category

Farm and Ranch › Fencing

Sold by

Pipestone Farm Supply, Millet, Alberta

Availability

In stock
